Dump Truck System Telescopic Hydraulic System for IATF 16949: 2016
Overview Package Size 2000.00cm * 500.00cm * 500.00cm Package Gross Weight 500.000kg Product Description Hydraulic Syste
Send your inquiryDESCRIPTION
OverviewBasic Info.
Model NO. | AY-S1 |
Acting Way | Double Acting |
Working Method | Straight Trip |
Adjusted Form | Regulated Type |
Structure | Telescopic |
Material | Carbon Steel |
Application | Dump Truck |
Color | Red, Black |
Feature | Convenient and Efficient |
Key Words | Hydraulic Parts |
Hydraulic Cylinders | FC Series |
Transport Package | Pallets |
Specification | oil tank system |
Trademark | ANWEEL |
Origin | Changzhou |
HS Code | 8412210000 |
Production Capacity | 300000pieces/Year |
Packaging & Delivery
Package Size 2000.00cm * 500.00cm * 500.00cm Package Gross Weight 500.000kgProduct Description
Product Description
Hydraulic System Principle and Composition
Series No. | Parts No. | Name of components | QTY | Series No. | Parts No. | Name of components | QTY |
1 | 0168 6817 | 5TG-F240×9030ZZ Hydraulic cylinder | 1 | 21 | 0182 6501 | Assembly parts of lifting valve | 1 |
2 | 0167 5329 | 4TG-F149×950 Hydraulic cylinder | 1 | 22 | 0183 3794 | Washer | 1 |
3 | 0182 9343 | Hydraulic cylinder lift support(Left) | 1 | 23 | 0183 3785 | Straight fitting | 1 |
4 | 0182 9257 | Hydraulic cylinder lift support(Right ) | 1 | 24 | 0183 3695 | L type fitting | 1 |
5 | 0182 8020 | Chassis Bracket | 2 | 25 | 0181 8766 | Hand control valve | 1 |
6 | 0182 7349 | Grease fitting | 4 | 26 | 0182 7583 | Assembly parts of hand control valve | 1 |
7 | 0182 3792 | Washer | 4 | 27 | 0182 6352 | T type fitting | 1 |
8 | 0182 3783 | Straight fitting | 5 | 28 | 0181 9545 | Limit valve | 1 |
9 | 0182 2654 | T type fitting | 2 | 29 | 0181 1651 | Oil tank | 1 |
10 | 0182 3796 | Washer | 2 | 30 | 0186 1182 | Air filter | 1 |
11 | 0182 3782 | Straight fitting | 2 | 31 | 0183 1569 | Assembly parts of air filter | 1 |
12 | 0182 7593 | Quick coupler(Male) | 1 | 32 | 0187 0077 | Ball valve | 1 |
13 | 0182 7586 | Quick coupler(Female) | 1 | 33 | 0187 0076 | L type fitting | 1 |
14 | 0185 2287 | CBW-DP100R-A1 Gear pump | 1 | 34 | 0187 0075 | Straight fitting | 1 |
15 | 0183 3791 | Washer | 1 | 35 | 0187 0062 | Oil tank absorber block | 1 |
16 | 0183 3788 | Straight fitting | 1 | 36 | 0184 3392 | 4000 High pressure oil tube. | 1 |
17 | 0183 3695 | L type fitting | 1 | 37 | 0184 3381 | 1500 High pressure oil tube. | 1 |
18 | 0183 1501 | L type fitting | 1 | 38 | 0184 3395 | 2500 High pressure oil tube. | 1 |
19 | 0185 3524 | Pump connector | 1 | 39 | 0184 2957 | 3000 Low pressure oil tube. | 1 |
20 | 0181 9205 | PT Lifting valve | 1 | 40 | 0183 6979 | Pipe clamp | 2 |
Certifications
Packaging & ShippingFAQ
Q1: Can your cylinders with HYVA ones ?
Yes, our cylinders can replace HYVA ones well, with same technical details and mounting sizes
Q2: What's your cylinder's advantages ?
The cylinders are made under strictly quality control processing.
All the raw materials and seals we used are all from world famous companies.
Cost effective
Q3: When your company be established ?
Our company be established in 1996, and we are professional for hydraulic cylinders for more than 25 years.
And we had passed IATF 16949:2016 Quality control system.
Q4: How about the delivery time ?
For samples about 20 days. And 15 to 30 days about mass orders.
Q5: How about the cylinder's quality gurantee ?
We have one year quality grantee of the cylinders.
